Sydney – Timber and
Working with Wood Show
Date: 27-29 July 2012 Venue: The Dome & Hall 2A Sydney Showground, Homebush Bay, Stand: H9
|
|
DIGITAL ANGLE RULER
|
|
|
Both measure the angle and length, metric and imperial display.Calculating angles quickly and accurately, digital display clearly. Easily operation with only two press button. Good locking function could lock the measurement at any angle. Hold function to save calculations. Compacted structure to achieve convenient carrying and using.
|
|
|
BOWL SANDER
|
|
|
Replaceable self aligning bowl sander. Features velcro pad, adjustable angle head, and dual ball bearings for smooth operation.
Kit includes semi soft and soft sanding head for 2" and 3", foam covered handle.
50pcs 2" sanding disc ( 10pc #80,10pc #150,10pc #240, 10pc #320,10pc #400)
50pcs 3" sanding disc ( 10pc #80,10pc #150,10pc #240, 10pc #320,10pc #400)
|
|
|
HOOK SANDING PAD
|
|
|
This
foam backed 2", 3" pad coming with soft ,semi soft disc holders provide
the perfect
cushion for precision contour bowl sanding. 1/4" (6mm)
shaft can be chucked in piston drill
running low speed for bowl sanding of woodturning.
|
|
|
TENONING JIG
|
|
|
This cast-iron tenoning attachment is an indispensible tool for
wood-working professionals and dedicated do-it-yourselfers wanting to
accurately cut stock at different angles. Great for cutting tenons,
splines, grooves, and chamfers. This tenoning jig simplifies complicated
cutting operations.
|
|
|
CHISEL SHARPENING SYSTEM
|
|
|
This sharpening Jig includes everything you need to grind perfect edges on your lathe chisels. The four piece set includes: (1) Adjustable "V" Pocket Jig-adjusts to accommodate chisels up to 27" long. (2) Grinding Platform-used for general purpose sharpening of all your chisels. (3) Finger Nail Jig-ideal for quick grinding of finger nail profiles on
shallow spindle gouges or side grinds on deep-fluted bowl gouges. (4) Skew Grinding Attachment-positions on the end of the "V" pocket jig to
assist you in grinding precision bevels on any skew chisel. ( Grinding Machine & Chisel not included )
|
|
|
END GRAIN RING TOOL SET
|
|
|
Set included 12" handle with 2pcs ( 9mm and 12mm) changeable ring cutters and 3pc resharpen kit.
HSS 12mm replace ring cutter (with 6.3mm shank) can build up your own hollowing tool.
|
|
|
CABINET SCRAPER SET
|
|
|
The handiest tool in the workshop. Remove milling marks and other
unwanted surface conditions from your project quickly and easily.The
ideal tool for working figured and exotic woods. The high carbon steel
body burnishes well and holds an edge.
|
|
|
STAINLESS STEEL DENTAL PICK & SCRAPER
|
|
|
These are the perfect tools for cleaning out cuts or detailing carvings,
even removing paint or finish from cracks and crevices when stripping. You’ll
find hundreds of uses around the shop. The set of four picks are double
ended. The set of four scrapers can be used as they come or
reground to a specific shape or purpose. Picks are 155mm overall, scrapers
are 135mm, all are stainless steel.
|
|
|
WATER STONE GRINDER
|
|
|
Easily sharpen blades, knives, and scissors with precision. Motor is 1/6HP 240V. 350 rpm
Wheel size: 180x20mmx12.7bore with 1000 grit.
|
|
|
SAW BLADE GRINDER
|
|
|
Saw blade 80 ~ 700mm, 2850RPM, Angle capacity ±20° Dish wheel: 125 x 10 x 32 x 8mm
|
|
|
T-TRACK CLAMP
|
|
|
Secure work piece easily to any T-track equipped jig hold down clamping. TTC-02P 2pc/set made by ABS. with M8x90mm sliding bolts and knobs , HTD-01 Made by Aluminum with protection. 25x135mm heavy duty hold down with 1/4" -20 sliding bolt and knob.
Working range: 0" to
2" ,
|
|
|
2-JAW PEN BLANK CHUCK
|
|
|
Drill a perfectly centered hole in your blank on your lathe using this
unique lathe chuck. The chuck includes two 2" jaws that will
hold your blanks perfectly centered at the headstock. Mount a
drill chuck with your drill bit into your tailstock and advance the
drill into your blank as it spins on your lathe.
|
|
|
UNIVERSAL BARREL TRIMMING SET
|
|
|
Squaring the end of the pen blanks is necessary for proper pen making.
This kit easily shaves blank ends in perfect alignment with the barrel
bore. Includes 7mm, 8mm 10mm and 3/8" pointed arbors, 3/4" squaring
cutter, adapter sleeve for pencil kits and allen wrench.
|
|
|
OVAL / CIRCLE CUTTER JIG
|
|
|
Perfect ellipses and circles with your router. It's never been so easy to
make ellipses, elliptical frames and circles. Thick ellipses like those
on old mirror frames are easy to do. Cut circles from 25" to 88" in diameter. Cut ellipse from 23" x 19" up to 97" x 92". Cut ellipses with a major/minor diameter difference of up to 9". 3 rod sizes fit any router.
|
|
|
ADJUSTABLE ROLLER STAND
|
|
|
3 Adjustable Roller Positions, Solid steel construction ,Provides level support with infeed and outfeed operations, Great work stability for Router Table , Miter Saws, and Planer. Roller supports lock at three angled positions, providing maximum flexibility, Height adjustable 12" wide ball bearing steel rollers.Stand adjusts from 28-1/2" to 32" tall, Non-slip rubber feet prevent motion during use. These legs will attach to any platform, creating a sturdy tool stand.
|
|
|
BENCHTOP ROUTER TABLE
|
|
|
23-3/4" x 15-3/4" Router Table Top, 23-3/4" Router Table Fence. Miter Track / T-Track / Hardware
More than 250Lbs load capacity.
( Router machine not included )
|
|
|
HORIZONTAL ROUTER TABLE
|
|
|
This is one of the most unique router tables yet it's also one of the
handiest and versatile in the shop. A horizontally mounted router that
can be finely adjusted allows the woodworker to use vertical raised
panel bits with ease and safety. The large table surface supports the
largest doors. With a few shop made jigs, it's also the perfect
mortising machine.
( Router machine not included )
|
|
|
PARROT VICE
|
|
|
The Parrot Vise incorporates a unique tightening cam that lets it pivot
freely through 360° until you tighten the jaws firmly, locking the vise
in place. This allows you to back off the clamp screw just enough to
rotate the vise for access to any part of a workpiece without releasing
it from the jaws. Additionally, the vise can be lifted from its heavy
pivot post and reinstalled horizontally (either side up), maintaining
the same pivoting and locking functions.
|
|
|
WOOD MOISTURE METER
|
|
|
Material range : Wood, Bamboo, Tobacco, Cotton, Paper, etc.
EM2G(2point) Measure Range: 6~25%, Accuracy: 2%, Display:LED, Resolution: 1%, Power: 9v 6f22 battery. EM4G(4point) Measure Range: Low 7~15%,High 16~35%, Accuracy: 1%, Display:LED, Resolution: 1%, Power: 9v 6f22 battery.
|
|
|
2 in 1 DOWELING JIG KIT
|
|
|
Easily match Face-to-Edge or Edge-to-Edge holes for dowel joining. Will
drill the following hole sizes: (inch.) 1/4", 5/16", and 3/8" or (metric) 6, 8, and 10mm.
Holds stock up to 1-1/4".
It needs no markings. Drill holes for edge to edge and edge to surface edge dowel joints.
|
|
|
VENEER ROLLER
|
|
|
The
differences are in the handle design.These rollers efficiently apply operator pressure to laminates and
veneers for positive glue contact. Both have comfortable grips and
rubber roller for even pressure distribution. The handle come in two
different styles with 3" wide roller.
|
|
|
STICK ON TAPE RULE
|
|
|
New Metric (1200mm)
1/2" (13mm) wide tape, Peel off the back to expose the adhesive, and apply where meet your shop needs.
|
|
|
FRONT VICE / END VICE
|
|
|
Hardware for cabinet marker's bench.
Front Vice: 13" length x 9" width. 1" diameter x 10" length screw.
End Vice 15" length x 4" width. 1" diameter x 14" length screw.
Quick Release Front Vice 17" length x 11" width. 1" diameter x 14" length screw.
|
|
|
BROACH CUTTER / ADAPTER
|
|
|
HSS-E or Tungsten Carbide Tipped, Suit 19mm shank Slug Socket Magnetic Base Drill (MBD19 , MBD25) ,
Some size x 50mm depth available.
MT.2 or MT.3 adapter to suit broach cutter with 19mm shank ,Ideal for magnetic drill with MT.2 or MT.3, And bench and pedestal drill .
|
|
|
EARTH AUGER / POST HOLE DIGGER
|
|
|
Engine model : 1E44F-2A, Forced air-cooled, 2 stroke, single cylinder. Fuel tank capacity : 1.2 . Gasoline / Oil mix ration : 30:1 , Displacement 51.7ml/cc.
Engine Speed 8500rpm. Rated Power 1.4kw, Max Torque 2.3N.m , Carburetor Diaphragm Type.
Ignition : C.D.I , Starting : Recoil starter
|
|
|
ELECTRIC MOTOR
|
|
|
Single phase 240V/50HZ, 19mm Shaft, Start / Stop.
Base hole between center : 100 x 125mm
|
|
|
220x40 LOW SPEED WET SHARPENER
|
|
|
240V / 50HZ, 180W, Wet stone wheel size: 220x40mm, Leather wheel size: 220x30mm, Strop / Honing speed :125rpm. Motor no load speed : 2850rpm , Noise level <70db.
Include : Supper arm assembly, Straight edge jig, Angle protractor, Honing compound, Stone grader.
|
|
|
BRASS PLATED CHAIN
|
|
|
To stop box lid falling back, simply use ring hooks connect the chain between lid and base inside of box.
|
|
|
CONNECTOR BOLT
|
|
|
For joint furniture , this is a quick active joint part very useful connector, ( the other side using thread nut or cross dowel nut ,cap nut, etc.) It easy setting and mount on bolts for clean board-to-board joining of shelves and cabinet sides.
|
|
|
THREAD INSERT
|
|
|
Great for joining wood, chipboard, and plywood;
especially useful in knockdown furniture. Simply drill a pilot hole,
thread in the insert with a screwdriver or T wrench, then use a machine
screw or bolt to attach the other part.
|
|
|
SWIVEL SPINDLE CASTOR with BRAKE
|
|
|
If you have limited shop space, or just have a lot of materials to move
around, then just imagine the tremendous flexibility and convenience
you'll get by putting cabinets, carts, tools, and work stations on
wheels. 3" Caster, Double Locking, Swiveling with 3/8" Threaded Spindle.
|
|
|
SIGN-MARKING TEMPLATE SET
|
|
|
For making wooden signs, plaques, and nameplates.Templates included to
make 1-1/2" (38mm) and 2-1/2" (63.5mm) letters and numbers. Use 1/4" and
1/2" straight V-groove or Cove router bits for different letter styles. Self spacing system eliminates need to measure between letters. Clamps for holding templates frame to your workpiece. Template holder takes up to 8 letters for fast sign making.
|
|
|
INLAY KIT
|
|
|
The
guide bushes fit 30mm hole with bearing to trace the template. Kit
includes : 1 PC: guide bushes 1/4" hole with 17m bearing OD, 1 PC:
#JL5161 solid carbide 1/8" spiral downcut x 1/4" shank
|
|
|
UNIVERSAL BASE PLATE
|
|
|
After time, router base plates become scratched, worn or damaged from
use. Some routers come from the factory without accepting the industry
standard Porter Cable size router bushing. This universal plate Solves
these problems and adds visibility by being clear acrylic. Fits routers: Porter Cable 690,7529, 8529 Ryobi Most Models, Bosch 1615, 1617, 1618 ,Makita Most Models 315 275 000, 315 175 040, 315 175 050,315 175 060, 315 175 070, 315 275 100, 315 275 110, Fein FT 1800, Milwaukee 5615, 5616, 5619, Freud FT2000E, Hitachi M8V, TR12, M12V, Elu 177, Dewalt 621, 625, 616, 618
|
|
|
